Description
Comes with a standard manufacturers 5-year Warranty.
Key Features
- Rugged, ergonomic design
- Dash-Arc
- Smart Lift TIG
- Full featured DC TIG parameters
- ABAP: Active Balancing Air Passage
- Smart gas for optimised shielding gas consumption
- Fan on demand
- Voltage Reduction Device (VRD)
- Key power electronic component protection
- Overcurrent and overheat protection
Technical Data
Input voltage: AC 230V 50/60Hz
No load voltage: 62V
TIG
ieff: 12.1A
Rated input power: 6.2kVA
Current range: 5-200A
Rated duty cycle @ 40°C: 20%
MMA
ieff: 12.9A
Rated input power: 6.7kVA
Current range: 10-160A
Rated duty cycle @ 40°C: 20%
Efficiency: 86%
Power factor: 0.68
Idle state power: 25W
Protection class: IP23S
Insulation class: H
Dimensions LxW×H: 413 × 150 x 311mm
Weight: 7.5Kg
Recommended generator size: 9KVA
* Generator must have AVR
